Sick Lms511-Traffic Sensor Pro Laser Scanner

Sick Lms511-Traffic Sensor Pro Laser Scanner
Sick Ag
Laser Measurement Sensor
Lms511 Pro Outdoor
Lms511-Traffic
Ident No: 1 064 730
Operating Data:
Dc24v=
Ptyp= 22w
7w With Heating
Temp: -30°…+50°C
Ip67
Mac: 00:06:77:21:E6:59
Class 1
Standard Resolution:
Plus Output: 55.6w
Plus Duration: 3.6s
High Resolution:
Plus Output: 29.6w
Plus Duration: 2.9s
Wavelength: 905 Nm
Iec 60825-1
Power Supply Voltage:
Sensor: Vs= Dc 24v ± 20%
Heating: Vs Heat= Dc 24v ± 20%
Power Consumption:
Sensor Without Output Load: Typical 22w, Max. 25 W
Sensor With Output Load: Typical 46w, Max. 50 W
Heating: Additionally Typical 55w, Max. 65 W
Lms Length 1
Lms Width 1
Lms Axle
Made In Germany
Weight : 3.930 Kg
Ref No : 164334
