Larsen & Toubro Emx3-0053b-v4-c1-h Soft Starter

Larsen & Toubro Emx3-0053b-v4-c1-h Soft Starter
Larsen & Toubro
Supernova Series
Emx3-0053b-v4-c1-h
3 Phase, 200-440 Vac, 50/60hz
53a: Ac-53b: 3-10: 350, 25kw (35hp) 400vac
S/c Withstand: Type 1 Coordination, Hrc Fuses At Prospective 65ka Rms
Enclosure Rating: Ip20, Ul Open Type
Pollution Degree: 3
Aux. Terminals: 12-30awg, 1.5mm2 At Torque 0.5 Nm, 4.5 In-lb
Aux. Contacts: 10a @ 250vac Df 10%, A300, Ac15 6a @ 250vac
Power Terminals: 10-1/0awg, 6-50 Mm2, At Torque 4 Nm, 2.9 Ft-lbs
Copper Solid Or Stranded 60/75°c Conductors
En 60947-4-2
Control Supply: 220-440 Vac
110-210 Vac
24 Vdc Output
Made In New Zealand
Weight : 4.650 Kg
Ref No : 133573
