Gm International D1031q 4 Channels Switch /proximity Detector Repeater 250v

Gm International D1031q 4 Channels Switch /proximity Detector Repeater 250v
By Gm International S.r.l.
Model: D1031q
4 Channels Switch/proximity Detector Repeater
Ii (1) G [ex Ia] Iic
Dmt 01 Atex E 042 X
Uo=10.7v
Io=15ma
Po=39mw
Co= 2.23uf
Lo= 172mh
Lo/ro= 930uh/ω
Um= 250v
Tamb: -20 To +60°c
Supply: 10 To 30vdc
Max Power: 1.4w
Output Rating: 35v, 100ma
Class I, Division 2, Groups A,b,c,d
Temperature Code T4;
Class I, Zone 2, Aex Nc [ia] Iic T4
Class I, Zone 2, Ex Nc [ia] Iic T4
Class I, Division 1, Groups A,b,c, D;
Class Ii, Division 1, Groups E,f,g
Class I, Zone 0, Group Iic
Exia Iic X
[exia] Iic X
Ii (1) D [ex Iad]
I (M2) [ex Ia] I
Dmt 01 Atex E 042x
Ii 3g Ex Na Ii T4
Imq 09 Atex 013 X
Iecex Bvs 07.0027x
[zone 0]
[ex Ia] I
[ex Iad]
Made In Italy
Weight : 160 Gm
Ref No : 110825
