Gic 2andt0 Electronic Timer 28v

Gic 2andt0 Electronic Timer 28v
Gic
Manufactured By: General Industrial Controls
Marketed By: Larsen & Toubro Limited
Electronic Timer-series Micon 225
Signal Based Multi-function
Cat Id/no: 2andt0
Supply: 24-240vac/ Dc, 50hz/60hz
Timing: 0.1s-10h
Rev: R010|v004
O/p: 5a @ 240vac/ 28vdc
Iec60947
Ac15: 1.5a @ 240 Vac
Dc13: 2a @ 30 Vdc
Tolerance: -20% To +10%
Contact: 5a(Res.) @ 240 Vac/ 28 Vdc
Mode: A, B, C, D, E
Wiring: Awg 20 To 10, Cu 60/75°c
Drive: Ph1-ø 4.0mm, Torque 0.6 Nm (5.3 Lb.in)
Made In India
Weight : 110 Gm
Ref No : 132232
