Yokogawa Eja110a Differential Pressure Transmitter 30v

Yokogawa Eja110a Differential Pressure Transmitter 30v
Yokogawa
Dpharp Transmitter
Model: Eja110a
Suffix: -Ems4a-92da/Ku2/F1
Style: S1
Supply: 10.5-30 (42) Vdc—
Output: 4-20ma Dc—
Mwp: 16 Mpa
Cal Rng: 0 To 2500 Mmh2o
Disp Mode: Sqrt
Output Mode: Sqrt
No.: 91h806223 834
Ii 1g
No. Kema 02atex1030 X
Eex Ia Iic T4
Tamb -40 To 60˚C
Process Temp.120˚C
Ui= 30v
Li= 165ma
Pi= 0.9w
Ci= 22.5nf
Li= 730µH
Ii 1d
No. Kema 02atex2148
T65˚C (Tamb: 40˚C), T85˚C (Tamb: 60˚C),
And T105˚C (Tamb: 80˚C)
Ii 2g
Eex D Iic T6…T4
Temp. Class T6 T5 T4
Process Temp. 85 100 120˚C
Tamb -40 To 75 80 75˚C
Ii 3g
Ex Nl Iic T4
Enclosure: Ip67
Matl: Sus Silicone
Code: 110
Cpsl: M
Ms8h2bqj
Body (L): Baa
Diaphragm: K9n
82-Ft-1202b
Made In Japan
Weight : 4 Kg
Ref No : 165655
