Yokogawa Eja110a Differential Pressure Transmitter 30 (42) Vdc

Yokogawa Eja110a Differential Pressure Transmitter 30 (42) Vdc
Yokogawa
Dpharp Transmitter
Model: Eja110a
Suffix:-elb4a-92db/ku2
Style: S1
Supply: 10.5 – 30 (42) Vdc
Output: 4-20 Ma Dc
Mwp: 3.5 Mpa
Cal Rng: 0 To 250
Mmh2o
No: 91l808685 1.31
Gvcm-pt7211
Ii 1g
No.kema 02atex1030x Eex Ia Iic T4
Tamb-40(-15) To 60°c Process Temp 120°c
Ui=30v Ii= 165ma Pi= 0.9w Ci= 22.5nf Li= 730µh
Ii 1d:
No Kema 02atex2148
T65°c (Tamb: 40°c), T85°c (Tamb: 60°c)
And T105°c(Tamb: 80°c)
Ii2g:
No.kema 02atex2148 Eex D Iic T6…t4
Temp Class: T6 T5 T4
Process Temp: 85 100 120°c
Temb-40 (-15) To 75 80 75°c
Ii 3g:
Ex Nl Iic T4 Ui= 30v Ci= 22.5nf Li= 730µh
Tamb-40(-15) To 60°c Process Temp.120°c
Enclosure: Ip67
Ambient Temp 70°c
Heat-resisting Cable 90°c
Matl: Mon
Silicone
Code 110
Cpsl: L
Lm1g133l
Made In Japan
Weight : 4.540 Kg
Ref No : 115886
