Trafag 8202 Pressure Transmitter 36v

Trafag 8202 Pressure Transmitter 36v
Trafag Ag
Sensors+Controls
Pressure Transmitter
Navitrag N
Typ/Type: 8202
Nr: 866631 01
P: -1…2,5 Bar
Max: 6 Bar
10…36 Volt Dc
Output: 4…20ma
Ta 0…70°C
Max. 36v-
Load Resistance (Max.): (U Supply-12v)/20ma
U Supply: 12…34v Dc
Ip-Protection: Ip65
Torque Moment Pressure Connection: Max. 25nm
Operating Temperature: -25°C…+85°C
Media Temperature: -25°C…+125°C
Storage Temperature: -40°C…+85°C
Weight : 500 Gm
Ref No : 182189
