Tetra Pak Pme-1802-A-Cd2 Motor Controller 230 V

Tetra Pak Pme-1802-A-Cd2 Motor Controller 230 V
Tetra Pak
Danaher Motion
90430-67
Part.No: 53n012a
Revision: 0005
Type: Pme-1802-A-Cd2 Trans-Driv
Part No: 90430-0067
Power: 230 Vac
+15..-20%
Field 195 Vdc
Armature: 0-180 Vdc
Inp. Ext. Speed B. 0-10 Vdc. Ua= 0-120 Vdc
Inp. Ext. Speed C. 0-10 Vdc. Ua= 0-150 Vdc
High = Current Limit Low. 24v Logic
High= Ext. Speed. 24v Logic
Inp. Ext. Speed A. 0-10 Vdc. Ua= 0-180 Vdc
High= Int. Speed 2.24v Logic
High= Int. Speed 1.24v Logic
Int. Speed 3
+12 Vdc Output. Rout= 1k
+20 Vdc Output. Max 30ma
Current Limit: 2.5/1.2a
Cont. Current: 2a
415610 0086
Gme: 91013-232
Jj-01
94v-0
Made In Sweden
Weight : 490 Gm
Ref No(S) : 161869
