Terasaki At20 Air Circuit Breaker 45°c

Terasaki At20 Air Circuit Breaker 45°c
Terasaki Electric Co., Ltd.
Tempower
Air Circuit Breaker
At20
Poles: 3
Operational Volt.(Ue): 690 Vac
Rated Frequency: 50/60 Hz
Rated Current (In): 2000 A
Standard: Iec947-2
Utilization Cat.: B
Short Time With-stand Current (Icw):
1 Sec 50ka
3 Sec 45ka
Atps0021-b
Nk (88t224)
With Inst: Ac480v 65ka
Without Inst: Ac480v 50ka
Amb. Temp.: 45°c
Over-current Trip
Aor-1bs-al
Base Cur. Io: 2000a
Ct Rating Icr: 2000/5a
Rated Freq.: 50.60 Hz
Auxiliary Sw.
Axt-1c
2a 2b
Btxs0006-a
Av130502
16a 380v Ac
Axt-1ab
10p
5a 5b
Rqu2312a1
Magnet Hold Trigger
Att-1
3p
04658840020
02108-32
Made In Japan
Weight : 88.500 Kg
Ref No : 108622
