Terasaki Ap-20 Air Circuit Breaker 480v

Terasaki Electric Co., Ltd.
Air Circuit Breaker
Type: Ap-20
Iec 2000a
Freq: 50-60hz
Rule: Nk
Amb.Temp. 45°C
Ct Ratio: 2000:3
Short-Time Current 70ka 1 Sec.
Ha-6833-11-2
Poles: 3
Voltage: Ac 660v
Ta-5343-1-1
Nk (80t216)
Over-Current Trip
Aor-1cs-As
Base Cur. Io: 1600a
Ct Rating Ict: 2000/3a
S1-So: Ac100~250v
Dc100~250v
Sp-So: Dc 24v
Pqh9268b1
3 P|E|
Manual Stored |C|
Aor- 1cs-As |A|
Ct: 2000 A
Sht Voltage Trip |A|
Ac 450 V
Aux: 5a5b |A|
Ocr Alarm: 1a |C|
Inter Lock: 1b |A|
Position Indicator:
Conn/Test 1c |A|
Ta-5360-1-5 P20
Auxiliary Sw.
Axh-1
5p3a2b
Na-6024-1-4
5p2a3b
Na-6024-2-1
Ta-4023-1-1
09503.504
Voltage Trip Device
Avh-1
Ac420~480v
Na-5977-1
Type: Anp-1c-B
Code: B42-1a/A14-1b
Swg.No: J-0262
Dwg.No: J-0151
Weight : 163.500 Kg
Ref No : 191407
