Terasaki Ame-3 Air Circuit Breaker 100~115v

Terasaki Ame-3 Air Circuit Breaker 100~115v
Terasaki Electric Co., Ltd.
Air Circuit Breaker
Type: Ame-3
Rated Current Io: 160 (A)
Long Time Delay:
Cur. Setting I1: 1.15 X Io
Delay Time: 20 Sec At 1.2 X I1
Short Time Delay:
Cur. Setting I2: 4.0 X Io
Rated Volt. Ac 600v
Poles 3p
Nk (83t204)
Ta-7457-1-3
Motor Operator
Type: Tmc4me
Volt: Ac 100~115v
Amp: 1.0a
2h1035saa
Uvt Control Device
Ac 450v, 50/60hz
Ta-7102-2-2
Aux. Switch
Ac480v 3a Dc250v 0.3a
Ac250v 5a Dc125v 0.6a
Ta-7309-1-2
Ct Ratio
250/0.05a
Trn
4c
4ba (Off)
Japan
Weight : 17.300 Kg
Ref No : 125010
