| Attribute | Value |
|---|---|
| Brand | Telemecanique |
| Part Number | XCK MR54D1 |
| Catalog Number | 068194 x1 |
| EAN | 3 389110 681949 |
| Description | Switch Limit – Telemecanique XCK MR54D1 |
| Certifications | C |
| Model | XCK-MR |
| IEC Standard | 947.5.1 EN 60 947.5.1 |
| UI | 500V |
| Uimp | 6kV |
| AC Rating | AC 15 240V 3A |
| DC Rating | DC 13 120V 0.55A |
| IP Rating | IP 66 |
| Approval Mark | 0126 |
| Product Code | A300 Q300 |
| Country of Origin | France |
| Weight | 730g |
What is the Telemecanique XCK-MR Limit Switch XCK MR54D1?
The Telemecanique XCK-MR54D1 is an industrial automation system rotary head limit switch. Made by Schneider Electric in the well-established Telemecanique brand, this small yet extremely reliable switch offers accurate position detection and mechanical control in many applications. The XCK-MR54D1 is part of the rugged XCK-MR family, reputed for their ability to withstand adverse environments, mechanical longevity, and extended electrical lifespan.
Limit switches such as the XCK-MR54D1 are electromechanical and break or make electric contacts upon movement. They find applications in a wide range of control systems where position or movement limits need to be sensed and automated responses triggered.
Key Features
High Mechanical Durability: Designed for more than 10 million operating cycles with normal loads.
Accurate Rotary Actuation: Includes a rotary lever head enabling accurate triggering by angular movement.
IP66 Protection: Total dust sealing and protection against water jets at high pressure—perfect for demanding industrial environments.
Broad Electrical Ratings: Accepts up to 240V AC or 250V DC, convenient for the majority of industrial control panels.
Robust Body Design: Chassis-grade metal enclosure offers mechanical reinforcement and shock resistance.
Spring Return Operation: Guarantees reproducible resetting of the switch upon actuation.
Standardized Mounting: IEC and EN compatible for cross-panel and machine mounting.
Flexible Contact Arrangement: Includes 1 NO + 1 NC (Normally Open + Normally Closed) contacts for easy wiring.
Uses
This limit switch is used in industrial automation, machine protection, and process control applications where mechanical movement needs to be controlled or monitored. Typical application fields include:
Automated Conveyor Systems: In detection of end positions, jams, or presence of parts.
CNC Machinery & Robotics: As position feedback or end-stop control device.
Material Handling Equipment: Like elevators, hoists, and lifts.
Packaging and Printing Machines: For aligning and positioning components.
Marine and Offshore Systems: Applicable owing to high resistance to moisture and dust.
Industrial Doors & Safety Barriers: To initiate open/close signals or lock mechanisms.
Its rugged build and broad compatibility ensure it is a critical part in electromechanical systems that demand reliability and repeatability.
Why Select the XCK-MR54D1 for Your System?
Selecting the XCK-MR54D1 limit switch delivers several operational and performance benefits:
Reliable Brand:
Supported by Schneider Electric’s Telemecanique brand—famous for quality control products and automation innovation.
Its robust metallic casing and encased internals are designed to survive shock, vibrations, exposure to oil, and temperature changes.
Simple Maintenance & Integration:
Small size, pre-wired terminal connections, and common fittings minimize downtime for installation or replacement.
Precision in Movement Detection:
Rotary lever mechanism provides smoother and more accurate position detection than the older plunger-type designs.
Safety & Compliance:
Compliant with world-wide industrial safety regulations (EN/IEC) for reliable machine and operator protection.
