Telemecanique Altistart 3 Soft Starter 380v

Telemecanique Altistart 3 Soft Starter 380v
Telemecanique
Altistart 3
Ats 23c41q
Control:
Vw3g231m12q
1 Phase
220v-240v
380v-415v
8a Max.
Type Gl
50/60hz
Consumption: 15va
Input Currents: 20ma/24v—
Auxiliary Contacts: 15…54
380v~max.
Ith: 5a
Iec 337
Ac11: 240v 0,5a/380v 0,1a
Dc11: 48v 0,5a
B 300
383122-04
Power:
Vz8g231c41q
3 Phases
500a Max. Type Am
Nominal Motor Current: 420a Max.
Max. Continuous Current: 460a
Thermal Overload: 1.05lr
Thermal Trip: 1.11lr
Tripping Time At: 5lr 13s
Iec 146
Type: Ibg 750/1a
0,5cl 5va
1cl 7,5va
3cl 10va
Ith: 45ka
Fs Less Than 5
0.72/3/-kv
456063
France
Weight : 47.600 Kg
Ref No : 148353
