System Sensor B200sr Intelligent Sounder Base 33v

System Sensor B200sr Intelligent Sounder Base 33v
System Sensor
Intelligent Sounder Base
Fire Alarm Equipment
Fire Alarm Systems
Signaling
Model No: B200sr
Issue No: A-48,060
Continuous Tone At 10ft
Maximum Installation Temperature 120°f (49°c)
Base Diameter: 6.875″ (17.46 Cm)
Base Height (Less Sensor): 2.0″ (5.08 Cm)
Operating Temperature Range: 32° To 120°f (0° To 49°c)
Operating Humidity Range: 10% To 93% Relative Humidity (Non-condensing)
External Supply Electrical Ratings
External Supply Voltage: 16 To 33 Vdc (Vfwr)
Standby Current: 500 Μa Maximum
Alarm Current: 35 Ma Maximum
Slc Electrical Ratings
Slc Operating Voltage: 15 To 32 Vdc
Slc Standby Current: 300 Μa Maximum
Sound Output: Greater Than 85 Dba Minimum
U.s. Pat. No.: 596,974
1041
N04-4044-002
Type: 1041
L00-592-02
H58-0510-050
L01-0748-000
7 83863 03828 0
Assembled In Usa
Weight : 360 Gm
Ref No : 139534
