| Attribute | Value |
|---|---|
| Brand | Square D |
| Manufacturer | Groupe Schneider |
| Type | GAW-1 |
| Class | 9012 |
| Series | C |
| Product | Pressure Switch / Interrupter |
| Operating Range | 2-10 PSIG / 0.1-0.69 Bar |
| Classification | CL II Div 2 Gr F, G & CL III |
| Model Number | 9012GAW-1 |
| Rating | A800 / Q800 |
| Enclosure Type | Type 4, 4X, 13 |
| Barcode | 7 85901 02507 8 |
| Made In | Mexico |
| Weight | 2.010 kg |
What is a Pressure Switch?
A pressure switch is an instrument that senses pressure within a system and makes an electrical contact when the pressure is at a specified level. This contact can be utilized to control other devices, like pumps, valves, or alarms, to keep the pressure within the desired range.
Key Features and Specifications
The Square D 9012 GAW-1 is a heavy-duty pressure switch that can be used in demanding industrial applications. Some of its most important features and specifications are as follows:
Adjustable Pressure Range: The switch has an adjustable pressure range, which means it can be set up for different applications.
Durable Construction: Constructed with a tough enclosure, the 9012 GAW-1 is able to survive tough conditions and provide long-lasting performance.
High Accuracy: The pressure switch ensures precise and reliable pressure sensing for accurate control of your system.
Different Contact Options: The 9012 GAW-1 is offered in various contact options to meet your particular requirements.
Simple Installation: The switch has been made easy to install, and it can be easily incorporated into your system.
Applications of the Square D 9012 GAW-1
The Square D 9012 GAW-1 pressure switch has applications across a broad industry base, including:
Manufacturing: Regulating hydraulic and pneumatic systems.
Oil and Gas: Pressure monitoring in pipelines and processing equipment.
Water and Wastewater: Regulating water pressure in distribution systems.
HVAC: Regulating proper heating and cooling system operation.
Selecting the Right Pressure Switch
Choosing the proper pressure switch is important to maintaining the safety and efficiency of your system. Use the following guidelines when selecting a pressure switch:
Pressure Range: Identify the pressure range needed for your application.
Electrical Requirements: Make sure the electrical rating of the switch is compatible with your system.
Environmental Conditions: Take into consideration the environment the switch will operate in, including temperature, humidity, and exposure to harsh chemicals.
Accuracy and Repeatability: Select a switch that offers the accuracy and repeatability required for your application.
