| Attribute | Value |
|---|---|
| Brand | SOCLA |
| Model | 149B2527 |
| Figure | FIG.50 |
| Pressure at 20°C | 10 BAR |
| UL Code | UL1040 |
| Connection Size | G 2 1/2 |
| Liquid Pressure Range | 1/2 : 10/10 BAR |
| Gas Pressure Range | 1/2 : 10/10 BAR |
| Standard | EN12050-4 |
| Temperature Range | -10°C to +80°C |
| Serial Number | 256814 |
| Country of Origin | Made in France |
| Weight | 5.500 KG |
| Reference Number | 50144 |
What is a Ball Check Valve?
A ball check valve is a non-return valve that employs a weighted ball to seal the flow of liquid or gas in one direction. When fluid flows in the proper direction, pressure lifts the ball off the seat, and flow is permitted. If flow is reversed, gravity or back pressure forces the ball back into position, sealing the valve and stopping backflow.
Introduction to SOCLA 149B2527
SOCLA 149B2527 model is part of SOCLA’s reliable series of hydraulic valves. Renowned for accuracy and quality engineering, SOCLA produces valves according to strict global standards. The model in question is designed to perform at its best in extreme conditions and has great sealing properties.
Key Features
Design Type: Self-cleaning ball check valve.
Body Material: Usually composed of ductile iron or cast iron with corrosion-resistant coat.
Ball Material: Usually made of stainless steel or nitrile, offering chemical resistance and strength.
Installation Position: Available to be mounted horizontally or vertically (ball-down position).
Silent Operation: Built to avoid water hammering and run smoothly.
Low Maintenance: No periodic servicing required thanks to its minimal internal mechanism.
Technical Benefits
Efficient Backflow Prevention: Provides fluid direction for one way, avoiding contamination of the system.
Long Service Life: Reliable materials provide prolonged operating life despite severe conditions.
Versatility: Ideal for potable water, wastewater, and other industrial fluids.
Self-Cleaning Design: Reduces clogging and ensures flow efficiency.
Energy Efficient: Low-pressure drop through the valve translates to minimal pressure effect on the overall system.
Applications
The SOCLA 149B2527 Ball Check Valve is generally used in the following systems:
1. Water Supply Systems
Prevents contamination, directional flow in residential, commercial, and municipal water supply pipes.
2. Pumping Stations
Prevents water backflow upon pump shutdown, minimizing pressure surges and safeguarding pump equipment.
3. Wastewater Treatment Plants
Efficaciously handles waste liquids while avoiding reverse contamination of pipes.
4. Irrigation Networks
Applied to agricultural farms to ensure the right flow direction and system pressure within irrigation systems.
5. Industrial Processing Lines
Controls directional flow within chemical, food, and beverage processing systems.
