Smar Ld301 Pressure Transmitter 4…20ma

Smar Ld301 Pressure Transmitter 4…20ma
Smar
Pressure Sensor Model: M5
Range: 30 To 3600 Psi
Rating: 6000 Psi
Fill: Silicone Oil
Material: 316l Sst
Ld301 Pressure Transmitter
4…20ma
Br-ex D Iic T6 Cepel-ex-039/96-3
Br-ex Ia Iic T5 Cepel-ex-049/95-3x
Ii=100 Ma
Pi=0,7 W
Ui=30v
Li=desp.
Ci=6,4 Nf
T Amb= -20 A 50°c
Ip67
Class I, Gr. B, C, D; Class Ii, Gr. E, F, G; Class Iii
Class I, Div.2 Gr. A, B, C, D; Class Ii, Div.2 Gr. E, F, G; Class Iii
Enclosure Type 4x
Supply: 12-42 Vdc
Pmax: 3600 Psi
Ta: 40°c Max
Nema 4x/6 Temp.class: T4a
V Max.: 30 Vdc
I Max: 110 Ma
Ci: 8 Nf
Li: 0.24 Mh
Weight : 6 Kg
Ref No : 104212
