Siemens Sitrans Fc330 Digital Coriolis Flow System 240v

Siemens Sitrans Fc330 Digital Coriolis Flow System 240v
Siemens Ag
Sitrans Fc330
System Order No: 7me4633-3la11-1da3-Z
A01+B11+E02+F01+S30
Sensor Order No: 7me4630-3la11-1aa0-Z
Transm.Order No: 7me4603-2aa04-3ac0-Z
F01
Power Supply: 100-240vac
30va
47-63hz
20-27vdc
11w
Material/Version: Aluminum/Compact
Conduit/Cable Entries: 2xm20x1.5+M25x1.5
System Version:
Fw: 4.00.02
Hw: 03
Enclosure: Ip67/Type 4x
Tamb: -40°C/-40°F To 60°C/140°F
Sen. Rs: 02
Size Dn: 25
Cal. Factor: 3250224346
Qm (Min): 240kg/H
Qm (Nom): 20500 Kg/H
Is: Vi=20v, Ii=484ma, Pi=2.3w
Accuracy: 0.1% Flow. 2kg/M3
Mawp (Ps) At (Ts): -50°C/58°F: 40bar/580psi
Mawp (Ps) At (Ts): 200°C/392°F: 31.8bar/461psi
Sep
Wetted Material: 1.4435
Process Conn: 1.4404
En 1092-1/B1/11/Dn25
Din/En1092-1/B1/Dn25/Pn40
N200807av07 02
247184508×001
Function:
Hart Output 4-20ma/Output: Current, Frequency, Pulse, Status:
Description:
Rl Less Than 500 Ohm
A: Vo=28v, Io=87ma
P: Vi=30vdc, Ii=100ma
Made In France
Weight : 16.410 Kg
Ref No : 166831
