Siemens Sirius 3rw3026-1bb14 Soft Starter

Siemens Sirius 3rw3026-1bb14 Soft Starter
Siemens Ag
Sirius
Ac Semi Conductor Motor Starter
3rw3026-1bb14
*e05*
G/161208
Us: 110-230v
Iec/en 60947-4-2
Iec 60947-5-1
Gb14048.6/50hz
25,3a : Ac-53a:3-3:30-15
Ue: 200-480v 50/60hz
Aux Cont.: Short Circuit 1ka
230v Max
Ui: 300v
Ac-15:3a/230v; Dc-13:1a/24v
Uimp: 4kv
Ie: 25,3 A Less Than = 40°c
Ui: 600v
Uimp: 6kv
Fla 23 Less Than 50°c
Short Circuit 5 Ka
75°c Cu Wire Only
Aux.cont: B300 R300
Overload Protection With 3rv, 3ru Or 3rb Required
Surrounding Air Temp 50°c
Ø5…6mm
0,8…1,2 Nm
7…10.3 Lb.in
Torque: 18…22 Lb.in
2,0…2,5 Nm
Pz 2/ø5…6mm
Kcc-rem-s49-3rw
4 011209 719439
Made In Germany
Weight : 570 Gm
Ref No : 116483
