Siemens 7Me4603-2Ah04-3Ag0-z C10+F00 Coriolis Flowmeter 240V

Siemens 7Me4603-2Ah04-3Ag0-z C10+F00 Coriolis Flowmeter 240V
Siemens A/S
Flow Instruments
Coriolis Flowmeter
Sitrans Fc430
System Order No/ Transm.Order No: 7Me4603-2Ah04-3Ag0-z C10+F00
Power Supply: 100-240Vac, 47 To 63Hz 20-27Vdc 20Va
Material/Version: Aluminium, Compact
Conduit/Cable Entries: Npt 1/2”
System Revisions:
Fw: 3.02.02-01
Hw: 02
No: Normally Open Contact
Nc: Normally Closed Contact
Current Output: -4 To 20Ma
Rl Less Than 500 Ohm (Hart=230 Ohm)
Active: Vo=28V, Io= 90Ma
Passive: Vi= 30Vdc, Ii= 100Ma
Fw Revision: 3.02.02-01
Hw Revision: 02
System Order No.: 7Me4613-3Ja11-1Da3-z +A12+B11+C10+E06+F00
Sensor Order No.: 7Me4610-3Ja11-1Aa0-z +A00+B10+E00+F00+C10
Sen.Rs: 02
Sw Function: Standard
4-20 Ma, Act.Hart
Mawp (Ps) At 20°C: 40 Bar
Mawp (Ps) At 200°C (Ts): 31,8 Bar
Sep
Wetted Material: 1.4435
1.4404
Min.Fluid Temperature: -50 °C
Size Dn: 15
Conn.: En 1092-1 Dn25
Cal. Factor: 2426962441
Qm (Min.): 20 Kg/H
Qm (Nom.): 3700 Kg/H
Enclosure: Ip67/Nema 4X
Ambient Temp.: -40 To 60°C
Accuracy: 0.1% Flow. 5 Kg/M3
En/Pn40/1.4404/213019
Made In Denmark
Weight : 10.530 Kg
Ref No : 141968
