| Attribute | Value |
|---|---|
| Model Name | Shin Sung Sn400A Cable Fault Unit Cf-4244 Sn420A |
| Brand | Shin Sung |
| Product Type | Cable Fault Unit |
| Model Numbers | SN400A, SN420A, SN401A |
| Reference Code | CF-4244 |
| Input Voltage | +24V |
| Resistance Range | 10kΩ – 20kΩ |
| Compatible Modules | CF-04D / CF-O4D, SM-101 |
| Country of Origin | Made in Korea |
| Weight | 210 gm |
What is the Shin Sung SN400A Cable Fault Unit?
The Shin Sung SN400A series is specifically used to identify and locate faults in underground cables, power lines, and other electrical wiring systems. These units employ sophisticated fault detection technology to detect faults such as open circuit, short circuit, and high-resistance fault.
Two of the most important models in this series are:
- CF-4244 Cable Fault Locator
- SN420A Pulse Echo & Thumper Unit
Every unit has a critical role to play in rapid testing, finding, and confirming cable faults with minimal risk.
Key Features of the CF-4244 and SN420A Units
Let’s find out what makes these units stand out in cable testing.
1. Precision Fault Detection
Both models are designed to provide spot-on accuracy in fault detection of cables. Equipped with state-of-the-art pulse echo and time domain reflectometry (TDR) technology, they calculate the fault distance with high accuracy.
2. Intuitive User Interface
Although they are highly technical, Shin Sung units are renowned for being simple to use. Technicians are able to easily master the operation of the system through an easy-to-use control panel and straightforward readouts.
3. Miniature and Portable Design
With industrial-strength ruggedness condensed into a compact chassis, these units are designed for on-site use. Their portability enables testing in inaccessible locations without compromising performance.
4. Multiple Testing Modes
The CF-4244 and SN420A accommodate multiple fault detection methods including:
- Pulse echo
- Arc reflection
- Surge comparison
- TDR (Time Domain Reflectometry)
These modes of testing guarantee that a broad spectrum of fault types can be properly diagnosed.
5. Built-in Safety Features
Operations on high-voltage cables call for caution. Shin Sung has seen fit to load these models with surge protection, overload sensors, and grounding equipment to ensure that operators remain secure.
Applications
Such cable fault models are not isolated to a singular form of employment. Some examples of industries for which the CF-4244 and SN420A are precious assets include:
- Utility firms with the task of diagnosing underground power cable faults.
- Telecommunication companies finding break or shorts within data transmission cable lines.
- Industrial facilities guaranteeing smooth operation of motor control cables and power distribution systems.
- Railway and transport maintenance personnel identifying faults in signal and power lines.
Advantages of Utilizing the SN400A Series
Investing in the Shin Sung SN400A series has a number of advantages for professionals:
- Fault location faster translates into less downtime and faster repairs.
- Increased accuracy prevents unnecessary digging or cable replacement.
- Flexibility in testing enables technicians to diagnose a range of cable types.
- Cost-effectiveness through reduced labor and time during maintenance.
Why Shin Sung?
With decades of experience in the electrical testing equipment business, Shin Sung is a brand known and trusted by professionals across the globe. Their focus on quality, innovation, and user-friendly designs makes their equipment the first choice when it comes to cable fault diagnostics.
