| Attribute | Value |
|---|---|
| Brand | Schneider Automation SA |
| Model | TSXDMZ28DR |
| Series | TSX Micro |
| Product Version (PV) | 02 |
| Release Level (RL) | 02 |
| Input/Output Type | 16 Inputs (24VDC, Sinking/Sourcing) 12 Relay Outputs (240VAC / 24VDC) |
| Input Type | IEC 1131-2 Type 1 |
| Output Rating | Ith = 3A |
| Terminal Type | M3.4 |
| Standards | IEC 1131-2 |
| Country of Origin | France |
| Weight | 470 gm |
What Is the Schneider TSXDMZ28DR PLC Module?
The Schneider TSXDMZ28DR PLC Module is a high-performance I/O expansion module designed for the popular Schneider TSX Micro series. Engineered to deliver reliable, fast, and accurate input/output operations, this module plays a key role in industrial automation environments where precision, safety, and continuity are essential.
With 16 digital sinking/sourcing inputs and 12 relay outputs, the TSXDMZ28DR provides a balanced I/O configuration suitable for a wide range of control applications. It supports 24V DC inputs, 240V AC/24V DC relay outputs, and complies with IEC 1131-2 standards—making it a trusted component in machinery automation, process control, and plant operations.
The module is built with Schneider’s long-standing focus on industrial durability, offering stable performance even in demanding environments. Whether used in OEM machinery, manufacturing units, or marine automation setups, the TSXDMZ28DR ensures seamless communication with TSX Micro PLCs and maintains accuracy across control cycles.
Key Features of Schneider TSXDMZ28DR PLC Module
1. Balanced I/O Configuration
-
16 digital inputs (24VDC Type 1)
-
12 relay outputs (240VAC / 24VDC)
This configuration is ideal for mid-sized automation tasks requiring both sensing and actuation capabilities.
2. Highly Reliable Relay Outputs
Relay outputs support an Ith of 3A, allowing safe switching of motors, solenoid valves, small contactors, and general electrical loads.
3. Dual Operation Input Type
The digital inputs support both sinking and sourcing configurations, offering compatibility with different sensor types.
4. Compliance with Industrial Standards
Certified under IEC 1131-2, ensuring noise immunity, safe operation, and high electrical robustness.
5. Modular, Expandable Design
Integrates seamlessly into the Schneider TSX Micro PLC ecosystem, enabling flexible system expansion without redesigning entire panels.
6. Built for Harsh Environments
-
Industrial-grade construction
-
Stable performance in high-vibration, electrical noise, or marine automation conditions
-
Schneider’s proven reliability in automation hardware
7. Easy Installation and Wiring
Features M3.4 terminals and a compact form factor, allowing simple integration into control cabinets with limited space.
8. Lightweight for Industrial Standards
With a weight of 470g, it is easy to mount and service during preventive maintenance routines.
Applications of Schneider TSXDMZ28DR PLC Module
The TSXDMZ28DR is built to perform in a variety of automation environments. Its balanced input/output structure makes it ideal for:
1. Manufacturing & Factory Automation
Used in assembly lines, packaging machines, and process automation panels requiring stable digital control.
2. Material Handling Systems
Manages sensors, relays, conveyors, diverters, and safety interlocks in warehouses and distribution plants.
3. Marine Automation & Shipboard Controls
Due to the robust build, it is suitable for:
-
Engine control systems
-
Pump monitoring
-
Navigation support systems
-
Marine alarm panels
4. HVAC & Building Automation
Supports relay control of fans, dampers, pumps, safety switches, and monitoring devices.
5. OEM Machinery
Manufacturers commonly use this module in:
-
CNC systems
-
Packaging robots
-
Food & beverage machinery
-
Small industrial machines
6. Power & Utility Automation
Useful in low-voltage switchboards, substation monitoring panels, and electrical distribution equipment.
7. Process Automation
Ideal for systems requiring precise switching such as:
-
Chemical dosing
-
Water treatment
-
Boiler control
-
Pressure and flow monitoring
Why Choose Schneider TSXDMZ28DR for Your Automation Needs?
1. Schneider Reliability You Can Trust
Schneider Electric is one of the world’s most trusted brands in industrial control. The TSXDMZ28DR carries the same legacy of durability and long-term performance.
2. Versatile Integration
Fully compatible with TSX Micro PLC systems, making it perfect for upgrades, replacements, and expansions without modifying existing wiring.
3. Reduced Downtime
Relay outputs provide electrical isolation, preventing damage due to overload or transient spikes—ensuring equipment longevity and fewer breakdowns.
4. Cost-Effective System Expansion
Provides a wide range of inputs/outputs in a single module, reducing panel space and wiring complexity.
5. Ideal for Both Industrial & Marine Use
Designed to handle temperature variations, vibration, and electrical noise—common in marine and heavy industries.
6. Long Lifecycle Availability
Schneider ensures long-term product support and global availability of spares, reducing replacement challenges.
7. Easy Maintenance & Troubleshooting
Clear labeling, strong terminal design, and robust construction make servicing fast and hassle-free.
