| Attribute | Value |
|---|---|
| Brand | Schneider Automation SA |
| Model | TSX Micro TSXDEZ12D2 |
| Type | Digital Input Card (E6) |
| Category | Hytec C.C.T.V. System |
| Input Type | 12I 24V DC TBlk |
| IEC Standard | IEC 1131-2 |
| PV | 02 |
| RL | 02 |
| Part Number | 1453123 01A 20 03 |
| Additional Code | 1453124010230183507724 4P |
| Made in | France |
| Weight | 220gm |
What is Schneider TSXDEZ12D2 TSX Micro Input Module?
Schneider TSXDEZ12D2 is a digital input module made for the TSX Micro PLC family, belonging to Schneider Electric’s reliable Modicon line. The module takes digital signals from field devices and transfers them to the PLC for processing. With 12 discrete 24V DC inputs, the TSXDEZ12D2 is compact but high-performance, capable of supporting broad industrial automation applications.
It serves as an important interface between switches or sensors and the primary controller and hence is best suited for monitoring on/off status, safety interlocks, or machine states within automated systems. Like most PLC input modules, TSXDEZ12D2 provides real-time acquisition of data, improving the overall performance of the control system.
Features of TSXDEZ12D2 Input Module
12 Discrete Inputs: 24V DC source/sink digital signals
Compact Form Factor: Simple integration into space-constrained areas
Modicon TSX Series Compatibility: Smooth integration with Schneider PLC systems
LED Indicators: On-board LEDs for channel status
DIN Rail Mounting: Makes panel mounting easy
High-Speed Response: Provides timely data input for real-time applications
Electrical Isolation: Shields the PLC from voltage surges or grounding
Applications
This input module finds extensive applications in industrial automation systems in many industries. Some typical applications include:
Manufacturing Plants
Utilized in reading limit switches, push buttons, and sensors to drive conveyor belts, assembly robots, and packaging lines.
Marine Automation
Scans pumps, pressure switches, or navigation sensor signals—perfect for ship automation panel integration.
Process Control Systems
Receives input from valves, temperature alarms, or safety cutoffs on oil & gas, chemical, or food processing plant lines.
HVAC & Building Automation
Captures thermostat, door sensor, or emergency stop switch data in centralized control systems.
Energy Management Systems
Interfaces with breaker status indicators, load controllers, or system alarms in power distribution and renewable energy plants.
Why Use Schneider TSXDEZ12D2 Input Module?
Selecting the TSXDEZ12D2 is making a smart investment in Schneider Electric’s reputation for quality and performance. Here’s why it excels:
Plug-and-play installation: Minimize setup time with an easy-to-use design.
Scalability of the system: Install additional modules as your system expands.
Long-term performance you can count on: Built to last in industrial environments.
Simple troubleshooting: LED lights simplify quick determination of input channel faults.
Brand you can trust: Supported by Schneider Electric’s world-class service and support.
In replacement or upgrade scenarios, the TSXDEZ12D2 delivers unmatched reliability and efficiency.
