Samwha Eocr-Fdm-500-S-220 Converter 300v

Samwha Eocr-Fdm-500-S-220 Converter 300v
Samwha Eocr Ltd.
Shinhwa
Converter
Eocr-Fdm
Eocr-Fdm-500-S-220
Overcurrent Setting (Is): 0.1~800a
Undercurrent Setting: Less Than O.C Setting
Time Setting: Sw3
Start (D-Time): Off, 1~200s
Trip (O-Time): 0.2~30s 1~30s
Alert Setting: 50~100% Of Is
Power Supply: 85~250vac/Dc, 50/60hz
Output Relay:
Ol 2-Spst
Al 1-Spst
3a/250vac Resistive
Trip Time:
Over-Current: O-Time In Greater Than Is
Phase Loss: Within 3s 1a (05 Type)
Phase Unbalance: 8s Deviation Greater Than 50%
Phase Reverse: 0.1s Rpr Sw. On
Locked Rotor: 0.5s 2~10 Times Of O.C
E97577
Awm 2464
Vw-1
80°C 300v
26awg
Ll87299 Csa
Awm T2 80°C Ft1
Made In Korea
Weight : 310 Gm
Ref No : 180300
