| Attribute | Value |
|---|---|
| Brand | Samson |
| Model | Trovis 6493 |
| Temperature Unit | °C |
| Input IN1 | 0(2)…10 V / 0(4)…20 mA |
| Input IN2 | Pt100/1000 -100…500°C / R 0…1 kΩ |
| Binary Input (BI) | 24 V DC |
| Output Y | 0(4)…20 mA |
| Output Y1 | 230 V AC 1 A |
| Output Y2 | 230 V AC 1 A |
| Output Φ | 20 V DC 25 mA |
| Alarm Relay (AR) | 50 V DC 30 mA |
| Power Supply | 90-250 V AC, 47-63 Hz, 13 VA |
| Model No. | 6493-0114.02 |
| VAR-ID | 1393856 |
| MP Number | 703398 MP 203 |
| Country of Origin | Made in Germany |
| Weight | 310 gm |
What is the Samson Trovis 6493 Compact Controller?
The Samson Trovis 6493 is a microprocessor digital controller that is used to control temperature, pressure, flow, and other process variables accurately. It is designed to be easily integrated into simple as well as complex control loops. The 6493-0114.02 model is one specific model in the 6493 series, specifically designed for compact applications where there is limited space but performance is not to be sacrificed.
Key Features of the Trovis 6493
• Space-Saving Design:
Small size makes it easy to fit into control panels or cabinets where space is at a premium.
• Versatile Application:
Ideal for numerous processes in heating, ventilation, air conditioning, and industrial automation.
• High Control Precision:
With PID control and auto-tuning feature, it provides stable operation and accurate control even under varying conditions.
• Easy-to-Use Interface:
With a clean display and intuitive programming features, it becomes simple for engineers and operators to manage.
• Digital & Analog Inputs/Outputs:
Provides versatile connection points for actuators and sensors, promoting compatibility with other automation devices.
• Modular Communication Options:
Can be added into existing systems using standard protocols such as Modbus, ensuring easy remote monitoring and control.
• Programmable Functions:
Personalized control strategies can be applied without the need for external PLCs, lowering cost and system complexity.
Applications of the Samson Trovis 6493 Controller
The Trovis 6493 is general-purpose and has application in many industries:
• Industrial HVAC Systems:
Provides ideal environmental conditions by controlling temperature, pressure, and humidity.
• Energy Plants:
Manages fuel or air flow to maximize combustion processes, increasing efficiency and lowering emissions.
• Chemical & Petrochemical Plants:
Provides rock-solid process control for reactors, mixers, and other highly important systems in need of careful control.
• Water Treatment Plants:
Controls pH, flow rate, and chemical dosage for clean and safe water treatment.
• Pharmaceutical Manufacturing:
Provides strict control of temperature and pressure for delicate processes, of critical importance for quality and regulation compliance.
Why Use the Samson Trovis 6493?
In the modern, high-speed industrial world, inefficiency and downtime can be expensive. The Samson Trovis 6493 provides a solid, smart, simple solution to assist plant operators and manufacturers in maintaining command of their operations. Its durable design, flexibility of integration, and precise control abilities make it the first choice of process engineers.
