Rosemount Emerson 3051 Cg4a02a1ks5i1m6p1q4 Pressure Transmitter

Rosemount Emerson 3051 Cg4a02a1ks5i1m6p1q4 Pressure Transmitter
Rosemount
Emerson Process Management Gmbh & Co.
3051 Cg4a02a1ks5i1m6p1q4
Overpr. Limit: 250 Bar
Range Limits: -17 + 20.7 Bar
Span: 0-0.21/20.7 Bar
Calibrated: 0 To 1000 Kpa
W.-nr.: 8672499 03/09
Ingress Protect: 66
Output: 4-20 Ma
Power Supply: 10.5-55 Vdc
Diaphragm: 316l Sst
O-ring: Tfe Gl
Integral Manifold Model: 0305rc22b11l4
Model: 3051/3001 Pressure Transmitter
Eex Ia Iic T5 (Tamb = -60 To 40°c)
Eex Ia Iic T4 (Tamb = -60 To 70°c)
T80°c (Tamb = -20°c To 40°c)
Bas97atex1089x
Ui= 30 Vdc
Ii= 200 Ma
Pi= 0.9w
Ci=0.012µf
Ii 1 Gd
Ip66
Rev.: Ac
03031-0060-0033
P/n: 03031-0332-0003
Label: 3031-621-1
Rev: Aa
For Connections In Ambients In Excess Of 60°c,
Use Wire Rated To At Least 90°c
8100-1825-0002
Rev: H
Xxxxx-0761-2042
Sissd4
4159500
Module Made In Usa
Product Of Germany
Weight : 4.330 Kg
Ref No : 141145
