Rosemount 3144p Temperature Transmitter 30vdc

Rosemount 3144p Temperature Transmitter 30vdc
Rosemount
Temperature Transmitter
Hart
Model: 3144p
Aus Ex 02.3794x
Ex Ia Iic T6 (Tamb=-60°c To +50°c)
Ex Ia Iic T5 (Tamb=-60°c To +75°c)
Power/loop:
Ui=30vdc
Ii=300madc
Pi=1.0w
Ci= 0.005µf
Li=20µh
Sensor:
Uo=13.6 Vdc
Io= 100madc
Po=80mw
Co=0.66µf
Lo=1.9mh
Ex N Iic T6 (Tamb=-60°c To +50°c)
Ex N Iic T5 (Tamb=-60°c To +75°c)
55 Vdc Maximum
Aus Ex 02.3813x
Ex D Iic T6 (Tamb=60°c)
Conduit Entry 1/2 -14 Npt
Ip66
03144-0164-0004 Rev Ad
03144-0151-0001 Rev.ab
Weight : 4.260 Kg
Ref No : 110951
