Rosemount 3051cd1a22a1ai1l4 Pressure Transmitter

Rosemount 3051cd1a22a1ai1l4 Pressure Transmitter
Rosemount
Emerson Process Management Gmbh & Co.
Smart Family
Hart
Model: 3051 Electronics
3051cd1a22a1ai1l4
Stat.pressure: 140 Bar
Range Limits: -62/+62 Mbar
Span: 0-1.25/62 Mbar
Calibrated: 0 To 10 Mbar
Ingress Protect: 66
Output: 4-20ma
Power Supply: 10,5-55vdc
Flange: 316 Sst
Diaphragm: 316l Sst
O-ring: Tfe Gl
8100-1825-0001
Rev.g
B4s97atex1089x
Eex Ia Iic T5 (Tamb=-60 To 40°c)
Eex Ia Iic T4 (Tamb=-60 To 70°c)
T80°c (Tamb -20°c To 40°c)
Ui= 30 Vdc
Ii= 290 Ma
Pi= 0.9 W
Ci= 0.012µf
Ii 1 Gd
03031-0060-0083
Rev.ac
Ip66
Xxxxx-0761-0012
14440544
Sissd1
R60477
P/n: 03031-0001-0002
Low Alarm: I 3.75ma
Low Saturation: I=3.9ma
High Saturation: I=20.8ma
High Alarm: I 21.75ma
Label: 3031-620-1/ab
Ym Hv 7 1 E
316
Module U.s.a
Product Of Germany
Weight : 3.060 Kg
Ref No : 128985
