Rosemount 3051 Cg3 A22a 1b I1 L4 Pressure Transmitter

Rosemount 3051 Cg3 A22a 1b I1 L4 Pressure Transmitter
Rosemount
Fisher-Rosemount Mfg Gmbh & Co.
Smart Family Hart
Pressure Transmitter
Model 3051
Eex Ia Iic T5 [Tamb= -60 To 40°C]
Eex Ia Iic T4 [Tamb= -60 To 70°C]
Umax: In= 30 Vdc
Wmax: In= 0,9 W
Imax: In= 200 Ma
Baseefa Nr. Ex 89c2360
Ceq= 0,012µF
03031-0060-0007 Rev. M
03031 0761 0032
1324817 Sil Sst Dp3
Overpr. Limit: 250 Bar
Range Limits: 0 Mbar Abs/+2480 Mbar
Span: 0-25/2480 Mbar
Calibrated: 0-2480 Mbar
3051 Cg3 A22a 1b I1 L4
8100-1825-0002 Rev. D
Ingress Protect.: 66
Output: 4-20ma
Power Supply: 10,5-55vdc (Not For Eexia)
Material:
Flange: 316sst
Diaphragm: 316sst
O-Ring: Tfe Gl
P/N: 03031-0332-0003
Label: 3031-621-1/A
Model: 3051/3001 Electronics
P/N: 03031-0001-0002
Std. Alarm/Saturation Levels
Low Alarm: I 3.75 Ma
Low Saturation: I= 3.9ma
High Saruration: I= 20.8ma
High Alarm: I 21.75 Ma
Label: 3031-620-1/Ab
Product Of Germany
Module Made In U.S.A.
Weight : 3.180 Kg
Ref No : 100122
