Rolf Janssen Bm 06 Pcb Module

Rolf Janssen Bm 06 Pcb Module
Rolf Janssen Gmbh
Elektrotechnische Werke
Operating Engine 4
Betriebsschalter / Stop / Operation Switch
Nr. 232
Delay Time: 0.5 – 30 Sec
S1 Overspeed
S2 Lub. Oil Press. Eng.
S3 Lub. Oil Press.
S4 Oilmist In Crankcase
S5 Main Bearg. Temp.
S7 El. Gov. Failure
S10 Contr. Medium
R2 Cool. Wat. Press. Eng.
R4 Exhaust Gas Temp
R5
R6
A1 Wire Break Safety
A2 Failure Overspeed
M1 Emerg. Stop Safe Device
M2 Emerg. Stop Contr. St.
Bm 06
Nr. 229
Index: X 2 3 4 5 6 7 8/1
S8 Load Sharing
S9 Operation Speed Low
Index: X 2 3 X 5 6 7 8/1 4
S6 Coo. Wat. Temp. Eng.
R1 Lub. Oil Temp. Eng.
R3 Cool. Wat. Temp. Eng.
Am-Ie-Lz
1 X 3 4/2
03.0111.A
Drahtbruchueberwachung/ Wire Break Monitoring
Typ/Type: Dbu 06/24
Nr. 233
F24.230/01
Index: 1
Weight : 3.600 Kg
Ref No : 164562
