Rolf Janssen Blkh 06 Wire Break Monitoring Operation Switch

Rolf Janssen Blkh 06 Wire Break Monitoring Operation Switch
Rolf Janssen Gmbh
Elektrotechnische Werke
S.-Syst.
Blkh 06
Nr. 230
Operation Aux. Eng. 2
Betriebsschalter/ Power Switch/Stop
S1 Overspeed
S2 Lub.Oil Press.Eng.
S3 Lub.Oil Press.Turb
S4 Oil Mist In Crankcase
S5 Main.Bearing
S7 Generator Failure
S8 Override S6 On
R2 Cooling-Water
R4 Exhaust Gas Temp.
A1 Wire Break Safety-
A2 Failure Overspeed-
M1 Emerg.Stop Safety
M2 Emerg.Stop Control-
M3 Emerg. Stop Mimic-
Bm 06 Nr: 229
Index: X 2 To 8/1
S6 Cool. Wat. Temp. Eng.
R1 Lub. Oil Temp. Eng.
R3 Cool. Wat. Temp. Eng.
87˚C
Am-Ie-Lz
1 X 3 4/2
03.0111.A
Wire Break
Drahtbruchueberwachung/Wire Break Monitoring
Typ/Type Dbu 06/24
Nr: 233
Weight : 3.730 Kg
Ref No : 179123
