Precision Digital Pd688-0k0 Loop Powered Meter

Precision Digital Pd688-0k0 Loop Powered Meter
Precision Digital
Loop Powered Meter
Model: Pd688-0k0
Model: Pd688/Pd689
Power: 4-20ma, 120 Mw
Max Loop Voltage: 30 V;
Max Loop Current: 30 Ma
Enclosure: Fm Type 4x & Ip65 Front
Input / Output: Ui: 30 V; Ii: 175 Ma Ci: 0; Li: 0; Pi: 1.0w
Cl: I, Div: 1; Gr. Abcd; Cl. Ii Div.1; Gr.Efg; Cl.Iii,Div.1; T4
Class I, Zone 1, Iic T4
Cl.I, Div.2,Gr.Abcd; Cl. Ii, Div.2 Gr. Fg; Cl.Iii, Div.2; T4;
Class I, Zone 2, Iic T4
Class I, Zone 0, Aex Ia Iic T4; Max Ambient Temp: 149°F (65°C)
Ex Ia Iic T4 Csa 1813992 X 06; Max Ambient Temp: 65°C
Ex Ia Iic T4
Ta= -40°C To +65°C
Fm08atex0058x
Els688
Assembled In Usa
Weight : 160 Gm
Ref No(S) : 113272
