Pepperl+fuchs Wem-fsu Frequency Converter 115 V

Pepperl+fuchs Wem-fsu Frequency Converter 115 V
Pepperl+fuchs
P+f
Wem-fsu
Part No: 15878
Supply: Unenn -15%+10%/ 45-65 Hz
Supply Select: 115 Vac / 230 Vac
Possible Exponents:
Ja= 0-20 Ma
Ja= 4-20 Ma
Output Delay:
T= 2n+1/fn
Output Delay= 2.5 S
Frequency Range: 0.001hz-999 Hz
Outputs:
Impulse Output (Terminals 10 And 11)
J: 10ma
U: 30v
Measured Value Ua (Proportional Ja)
Ua= 0-200 Mv
Measuring Instrument With Ri: 10 Mohm
Analogue Output (Terminals 12 And 13)
Operating Values:
2-wire-technique
Terminal 7.8
Namur Din 19234
Uo Ca/ac 8v
Jk Ca/ac 8ma
3-wire-technique
Terminal 6,8,9
U= 24v ± 15 %
Jmax= 20ma
Made In Germany
Weight : 430 Gm
Ref No : 130040
