Pepperl+fuchs We77/ex1-2u Switch Amplifier 500v

Pepperl+fuchs We77/ex1-2u Switch Amplifier 500v
Pepperl+fuchs
We77/ex1-2u
Part No: 07125s
115vac
Control Circuit [eex Ia] Ii C
Ptb Nr.ex-79/2043x
Operating Values:
Uo: Ca.8v
Jk: Ca.8ma
Namur
Din 19 234
Maximum Values:
Uo: 13,5v
Jk: 31ma
Ci: 71nf
P Max.: 125mw
Application [eex Ia] Ii C
Ca: 230nf
La: 3mh
Application [eex Ib] Ii C
Ca: 609nf
La: 31mh
Output: Changeover Contact
250vac/4a/500va Cos Φ 0,7
Supply: U Nenn -15% +10%/45-65hz Ca.3,5 Va
Cl.i,div.1,gr.a, B, C, D;
Cl.ii, Div.1, Gr.e, F, G;
Cl. Iii, Div.1
18151708857076
Germany
Weight : 380 Gm
Ref No : 153606
