Pepperl+fuchs Khd2-ss1/ex2 Isolated Switch Amplifier 250v

Pepperl+fuchs Khd2-ss1/ex2 Isolated Switch Amplifier 250v
Pepperl+fuchs
Rs
K-serie/ Series
Khd2-ss1/ex2
Part No: 20652s
Control Circuit
[eex Ia] Iic
Ptb Nr. Ex-89.c.2073
Namur Din 19234
Operating Values:
Uo: Ca/ac 8v
Jk: Ca/ac 8ma
Maximum Values:
Uo= 12.7v
Jk= 20ma
P= 63.5mw
Application [eex Ia]iic
Ca: 415 Nf
La= 2mh
Output:
U: 250vac
J: 2a
Cos Φ: 0.7
U: 30 Vdc
Supply 11-12: 24vdc ±15% 10%
Led 1.1, 2.1 Yellow
Led 1.2, 2.2 Red
Led 3 Green
Ambient Temperature 65°c
I-arbeitsstrom/working Current Mode A
Ii-ruhestrom/quiescent Current Mode R
285-396
Sev
[eex Ia] Iib, Iic
Asev 90.1 C02719
Weight : 150 Gm
Ref No : 133112
