Pepperl+fuchs Kfd2-sr2-ex1.w Switch Amplifier 500va

Pepperl+fuchs Kfd2-sr2-ex1.w Switch Amplifier 500va
Pepperl+fuchs
Kfd2-sr2-ex1.w
K-system
Part No: 373725
Ii (1) G D [eex Ia] Iic Ptb 00 Atex 2080
0102
Output
Ac: 253v 2a
500va
P.f. 0.7
Dc: 40v 2a
Um= 253vac
Supply Voltage: Dc 20-30v/
Current Consumption: 20-25ma
Ambient Temperature Max. 60°c
Maximum Values:
Uo=10, 5 V
Io=13ma
Po=34mw
Co=2.41µf
Lo=210mh
Eex Ia Iic
Class I, Div.1, Groups A,b,c,d
Class Ii, Div. 1, Groups E,f,g; Class Iii, Div.1
Electrical Ratings:
Supply: 24vdc, 50ma (Class 2)
Relay Contacts: 30vdc, 2a; 250vac, 2a, 0.7.p.f.
Ex Ia Ii C X D.96c.145
Kdb Nr. 96.561w Ip20
Made In Singapore
Weight : 120 Gm
Ref No : 114451
