Pepperl+fuchs Kfd2-sr2-ex1.w Switch Amplifier 40v 2a

Pepperl+fuchs Kfd2-sr2-ex1.w Switch Amplifier 40v 2a
Pepperl+fuchs
K-system
Kfd2-sr2-ex1.w
Part No: 103367s
Ii (1) Gd [eex Ia] Iic Ptb 00 Atex 2080
Ii 3 G Eex N A C Iic T4 Tuv 99 Atex 1493 X
Maximum Values:
Uo= 10.5v
Io= 13ma
Po= 34mw
Eex Ia Iic
Co=2.41µf
Lo=210mh
Output Ac 253v 2a
126.5v 4a
500va
P.f. 0.7
Dc 40v 2a
130v 20ma
80w
Supply Voltage: Dc 20-30v
Current Consumption: 20-25ma
Ambient Temperature Max. 60°c
Class I, Div 1, Groups A, B, C, D;
Class Ii, Div 1, Groups E, F, G;
Class Iii, Div 1
Electrical Ratings:
Supply: 24vdc, 50ma (Class 2)
Relay Contacts: 30vdc, 2a; 250vac, 2a
Tamb= -20°c To + 60°c
10353719615135
Made In Singapore
Weight : 110 Gm
Ref No : 119914
