Pepperl+fuchs Kcd2-stc-ex1 Smart Transmitter Power Supply

Pepperl+fuchs Kcd2-stc-ex1 Smart Transmitter Power Supply
Pepperl+fuchs
K-system
Kcd2-stc-ex1
Part No: 185535
Ii (1) G [ex Ia Ga] Iic
Ii (1) D [ex Ia Da] Iiic
I (M1) [ex Ia Ma] I
Ii 3 G Ex Na Iic T4 Gc
Cesi 06 Atex 021
Pf06cert0973 X
Ausgang/output:
I= 4-20ma
Eingang/input:
Hochstwerte/maximum Values:
Uo= 25.2v
Io= 100ma
Po= 630mw
Uo=7.2v
Io=100ma
Po=25mw
Ui=30v
Li=128ma
Versorgung/supply: Dc 19-30v/45-35ma
Um=250v
Umgebungstemp./ambient Temp.: -20°c Ta 60°c
Cl I, Div 2, Gp A-d;
Cl I, Ii, Iii; Div 1, Gp A-g
Temperature Code T4
Iecex Ces 06.0001
[ex Ia Ga] Iic
[ex Ia Da] Iiic
[ex Ia Ma] I
Made In Singapore
Weight : 100 Gm
Ref No : 68583
