Pepperl+Fuchs
K-System
Type: Kfd2-Sl2-Ex1.Lk
Part No.: 200542
Ii (1) G [Ex Ia Ga] Iic Zelm 99 Atex 0015
Ii (1) D [Ex Ia Da] Iiic
Ii (M1) [Ex Ia Ma] I
Ii 3 G
Ex Na Nc Iic T4 Gc
Tuv 02 Atex 1820 X
Logic Input: Um= 60v
Output:
Dc= 20-30v
Um= 40v
Ac 253v 2a P.F. 0.7
Dc 40v 2a
Supply: Dc 19-30v/120-60ma
Ambient Temp: -20°C Ta 60°C
Maximum Values: Uo= 28v
Io= 110ma
Po= 770mw
Cl I, Div 2, Gp A-D
Cl I, Ii, Iii, Div 1, Gp A-G
Cl I, Zn 2 Aex Na Nc Iic T4
Temperature Code T4 At Ta= 60°C
Made In Singapore
Weight : 170 Gm
Ref No : 159139
