Pepperl+Fuchs K-System Kcd2-Stc-Ex1 Smart Transmitter Power Supply 250v

Pepperl+Fuchs K-System Kcd2-Stc-Ex1 Smart Transmitter Power Supply 250v
Pepperl+Fuchs
K-System
Kcd2-Stc-Ex1
Part No.: 185535
Ii (1) G [Ex Ia Ga] Iic
Ii (1) D [Ex Ia Da] Iiic
I (M1) [Ex Ia Ma] I
Ii 3 G Ex Na Iic T4 Gc
Cesi 06 Atex 021
Pf06cert0973 X
Terminals 1,2
Maximum Values:
Uo= 25,2v
Io= 100ma
Po= 630mw
Terminals 3,4
Maximum Values:
Uo= 7,2v
Po= 25mw
Ui= 30v
Ii= 128ma
Output:
I= 4-20ma
Supply: Dc 19-30v/45-35ma
Um= 250v
Ambient Temp.: -20˚C Ta 60˚C
Cl I, Div 2, Gp A-D
Cl I, Ii, Iii, Div 1, Gp A-G
Temperature Code T4
4 000 003
8 376 762
Made In Singapore
Weight : 80 Gm
Ref No : 168633
