Panasonic Sf4b-H28c Compact Safety Light Curtain 24v

Panasonic Sf4b-H28c Compact Safety Light Curtain 24v
Panasonic Industrial Devices Sunx Co., Ltd.
Sf4b-C Series
Sf4b-H28c
Type 4
Ver.1.0
Height Of Defined Area: 583.4 Mm
Sensing Object: 25, 45, 65, 85 Mm Dia.Min.
Sensing Range: 0.3 To 7 M
Response Time: 14 Ms(Off),90ms(On)
Supply Voltage: 24vdc+/-10% Selv
Class 2 Circuits
Output: Ossds—24vdc +/-10%, 200ma Max.
Current Consumption: 85 Ma Max.
Enclosure Rating: Ip65
Ambient Temp: -10 To 55 Deg C
Type4 Espe, Sil3 (Iec 61508), Ple (Iso 13849-1)
Cc0000022
3w34
Made In Japan
Weight : 370 Gm
Ref No : 166519
