Omron H3ba-N Solid-State Timer 0-1.2 Min

Omron H3ba-N Solid-State Timer 0-1.2 Min
Manufacturer: Omron Corporation
Omron Europe B.V.
Dan Marine Group
Solid-State Timer
Time Relay
H3ba
Model/Type: H3ba-N
Mode: A
0-1.2 Min
Source/Volts: 220vac
Freq.: 50/60hz
Contact: 5a 250vac Resistive Load
(01)04548583344440
(21)268953539
Rated Supply Voltage:
110 Vac
220 Vac
24 Vdc
Operating Voltage Range:
85% To 110% Of Rated Supply Voltage
Power Reset Minimum:
Power-Opening Time 0.1s
Min. Pulse Width: 0.05 S
Power Consumption:
110 Vac Approx. 4.6 Va (1.5 W)
220 Vac Approx. 7.9 Va (1.3 W)
24 Vdc Approx. 0.6 W
Reset Voltage: 10% Max. Of Rated Supply Voltage
Control Outputs
Time Limit Contacts: 5 A At 250 Vac
Resistive Load (Cos փ= 1)
Ambient Temperature:
Operating: -10°C To 55°C (With No Icing)
Storage: -25°C To 65°C (With No Icing)
Ambient Humidity Operating: 35% To 85%
Time: 1.2 S To 300 H
Gb/T14048.5
4 548583 344440
Scsp20110486
Made In China
Place Of Origin: People’S Republic Of China
Weight : 130 Gm
Ref No : 97960
