| Attribute | Value |
|---|---|
| Manufacturer | Omron Corporation |
| Model | CS1W-OD232 |
| Type | Output Unit |
| Voltage | 24V DC |
| Current | 0.5A/P, 2.5A/C, 5A/U |
| Power (Resistive Load) | 24V DC (Res) (T) 0.5A/P, 2.5A/C |
| Power (P.D.) | 24V DC (P.D.) 12VA/P, 60VA/C |
| Certification | UL Class 2 Only, CSA |
| Serial Number | 041129_ 0014 |
| Origin | Made in Japan |
| Weight | 165 gm |
Overview of OMRON CS1W-OD232
The OMRON CS1W-OD232 is a transistor output unit that provides precise and effective control in industrial use. It is designed to directly replace OMRON’s CS1 series programmable logic controllers (PLCs) and provide a reliable means of controlling devices like solenoids, lamps, and relays.
Key Features
32-Point Output: The module has 32 output points, allowing the control of several devices in a small space.
Transistor Output: Using transistor-based outputs guarantees high-speed switching and reliability.
Rated Voltage: Compliant with 24V DC operations, it is suitable for a variety of industrial devices.
Screw Terminal Block: Easy and secure wiring connections.
LED Indicators: Integrated LED status indicators for immediate monitoring and troubleshooting.
Compact Design: Saves panel space and improves system efficiency.
Advantages of Using OMRON CS1W-OD232
1. Improved Reliability
With its transistor output, the CS1W-OD232 reduces wear and tear, providing long-term performance.
2. High-Speed Switching
While relay output units have slower switching speeds, transistor outputs provide a faster switching rate, which makes them suitable for time-critical applications.
3. Easy Integration
As a dedicated module for OMRON’s CS1 PLC series, installation and integration are easy and quick, which saves setup time.
4. Versatility in Industrial Applications
It can control a wide variety of output devices such as:
- Actuators
- Motors
- Solenoid Valves
- Alarm Indicators
5. Improved Safety and Monitoring
The LED indicators give real-time status information, enabling operators to monitor system operation and identify faults immediately.
Applications of OMRON CS1W-OD232
This output unit is commonly applied in the following industries:
1. Manufacturing & Assembly Lines
Multiple output devices are controlled by the unit, ensuring smooth operation of automatic assembly lines.
2. Packaging Industry
It is essential for controlling solenoid valves and actuators that are part of packaging machines.
3. Robotics & Motion Control
The high-speed switching function makes it a perfect fit for robotic arms and motion control systems.
4. Automated Warehousing
Employed for operating conveyor belt systems, to achieve handling and sorting of materials effectively.
