Mtl Sd32x Surge Protection Device 47v

Mtl Sd32x Surge Protection Device 47v
Mtl Surge Technologies
Made By Mtl Instruments Pvt. Ltd.
Surge Protection Device
Sd32x
Working Voltage (Un): 32v
Max. Continuous Operating Voltage (Uc): 36v
Breakdown Voltage Range: 45v-47v
Standby Operating Voltage: Less Than 32v
Rated Load Current: 400ma
Max. Resistance: 2.2ω/Line
Max. Line Inductance: 110µH/Line
Max. Surge Current (Imax): 20ka (8/20µS)
Impulse Current (Iimp): 2.8ka
Ex Ia Class I, Division 2, Groups A, B, C, D T4
Imax= 186ma
Li= 220µH
Ci= 0µF
Pmax=Pi=1w (-30°C Less Than Ta Less Than 75°C)
Or Pmax=Pi=1.2w (-30°C Less Than Ta Less Than 60°C)
Or Pmax=Pi=1.3w (-30°C Less Than Ta Less Than 40°C)
Isolated Loop Protector
Baseefa02atex0211x
Ii 1g
Eex Ia Iic T4
India
Weight : 60 Gm
Ref No : 161523
