| Attribute | Value |
|---|---|
| Product Title | MTL MTL5044 Two Channel Repeater Power Supply |
| Brand | Measurement Technology Ltd. (MTL) |
| Model | MTL5044 |
| Type | Two Channel Repeater Power Supply |
| Signal Type | 4/20mA for 2-wire transmitters |
| Certification | BASEEFA No. EX95D2339 (EN50 020) |
| Voltage Rating | Um = 250V |
| Max Ambient Temperature | 60°C |
| Output Specification | 28V, 300Ω, 93mA |
| Intrinsically Safe Field Connections | 28V max, 300Ω min (Terminals 1–2 and 4–5) |
| Hazardous Area Classification | Class I Groups A, B, C, D Class II Groups E, F, G Class III |
| [Ex ia] Rating | 20 to 35V DC, 130mA max |
| Country of Origin | Luton, England |
| Weight | 150 gm |
What is MTL MTL5044 Two Channel Repeater Power Supply?
The MTL MTL5044 Two Channel Repeater Power Supply is an industrial interface device designed to support intrinsically safe 4-20 mA measurement loops for field transmitters. It energizes and isolates two separate 2-wire transmitter loops located in hazardous areas, and repeats the transmitter current into safe-area measurement or control systems. This repeater power supply provides a fully floating DC supply and current repetition capability while maintaining signal integrity and safety compliance in demanding industrial environments.
In many industrial processes, instrumentation located in hazardous zones such as oil & gas, chemical plants, or marine environments requires safe and isolated power for sensors and transmitters. The MTL5044 fulfills this need by powering the field devices and transferring their signals safely to control equipment without exposing the system to hazardous area risks.
Key Features of MTL5044
The MTL5044 repeater has several robust features that make it ideal for process automation systems:
Two Independent Channels
Provides dual isolated support for two 4–20 mA loops, allowing simultaneous transmitter operation from one module.
Fully Floating DC Supply
Each channel offers floating DC power to energize hazardous area transmitters while avoiding ground loops and minimizing interference.
Hazardous Area Compatibility
Designed for use with intrinsically safe 2-wire transmitters in hazardous zones (Zone 0 / Division 1), subject to suitable certification.
Reliable Signal Repeat
Accurately repeats the 4–20 mA transmitter signal into the safe area, ensuring consistent and dependable current transmissions for monitoring and control.
Wide Supply Range
Operates from 20 – 35 V DC input, accommodating typical industrial DC power rails.
High Stability & Fast Response
Low temperature drift and fast settling time ensure stable, accurate output currents for critical processes.
Compact & Rugged Build
Designed to withstand industrial conditions with moderate power dissipation and robust terminal construction.
Applications of MTL5044 Repeater Power Supply
The MTL5044 module serves a wide range of industrial automation and control scenarios where reliable 4-20 mA signal power and integrity are essential:
Process Control Systems
Controls and monitors field transmitters in manufacturing and chemical processing, enabling safe loop powering and accurate data acquisition.
Oil & Gas Instrumentation
Used in hazardous area transmitter loops for pressure, level, temperature, and flow measurements where intrinsic safety is mandatory.
Marine Automation
Essential for vessels and offshore platforms where environmental conditions demand reliable and isolated instrumentation interfaces compatible with marine control systems.
Refineries & Petrochemical Plants
Supports critical analog instrumentation in areas with explosive atmospheres by safely energizing and repeating transmitter current signals.
Industrial Facility Monitoring
Useful in any industrial setting requiring isolation between hazardous field transmitters and safe area monitoring equipment.
Why Choose MTL MTL5044?
Safety-Focused Design
Its intrinsic safety and hazard zone compatibility dramatically reduce risk when powering field transmitters in explosive or flammable environments.
Dual Channel Efficiency
Two independent channels in a single module reduce rack space, simplify wiring, and lower overall installation costs.
Proven Signal Integrity
Highly accurate current repetition and floating supply ensure minimal signal distortion—critical for reliable instrumentation performance.
Industrial Reliability
MTL instruments are built for continuous use in demanding environments, maintaining performance across temperature and load variations.
Versatile Compatibility
Works seamlessly with a wide range of 2-wire 4–20 mA transmitters and control systems used across industries.
