MEASUREMENT TECHNOLOGY MTL 4041P HIGH POWER REPEATER POWER SUPPLY

Mtl 4041P Repeater Power Supply 4/20Ma For 2Or3 Wire Transmitter
measurement technology ltd.
mtl 4041p
high power repeater power supply, 4/20ma, for 2 or 3-wire transmitters
[eexia] iic
(en50 020)
baseefa no. ex92c2003
um = 250v
max. amb. 60°c
4/20 ma
int. safe field connections for cl. i, ii, iii,
div. 1, gps. a, b, c, d, e, f, g; also non –
incendive for cl. i, div. 2, gps. a, b, c, d. haz.
-loc. entity accord with mtl sci-421
temp. cl. t4.
intrinsically safe field connection 28v
max., 240 ohms min. (term 2/3 – 4/5) and 1.2v max.
20 ohms min (term 6 – 4/5) for class i, groups
a, b, c, d; class ii, groups e, f, g; class iii,
hazardous locations [ex ia]
supply = 28vdc max. 116.6ma max.
see installation drawing sci-439
vs 20-35vdc
14b2953x532
cl6351x1-a4
made in luton, england
weight: 110 gm
