Larsen & Toubro Csx-015-v4-c1 Soft Starter 240vac

Larsen & Toubro Csx-015-v4-c1 Soft Starter 240vac
Larsen & Toubro Limited
Csx
Soft Starter
Csx-015-v4-c1
O/c: Csx-015-41
Input Rating: 3 Phase, 200-440 Vac, 50/60hz
Output Rating: 34a: Ac-53b:4-6:354, 15kw (20hp) 400vac
Auxiliary Contacts: 6a 30vdc Resistive/2a 400vac Ac11
Withstand Current: 5000 A Rms, 575 Vac Max.
Power Contacts: #8-#10 Awg, 10-35 Mm, 3 Nm, 2.2 Ft-lbs
Auxiliary Contacts: #26-#24 Awg, 0.14-1.5mm2 (0.5 Nm, 4.4 In-lb)
Control Supply: 380-440vac Or 110-240vac
635-02368-00d
Initial Start Voltage: 30-70%
Start Ramp Time (Seconda) 2-20s Full Voltage Start
Stop Ramp Time (Seconds) 2-20s No Soft Stop
Weight : 2.580 Kg
Ref No : 136775
