Honeywell Stg644-e1g-00000-mb.p0d2-513c Smart Transmitter 42 V

Honeywell Stg644-e1g-00000-mb.p0d2-513c Smart Transmitter 42 V
Honeywell
Smart Transmitter
St3q00
Model: Stg644-e1g-00000-mb.p0d2-513c
Factory Cal: 0 To 125 Psi
Csa Enclosure 4, Nema 4, Ip65
Term.voltage: 11-42 Vdc 4-20 Ma Dc Output
6556-002
Temperature Limits:
Body: -40°c To +125°c
Ambient: -40°c To +93°c
Bs 4683 Part 3 1972
Ex N Ii T6
Baseefa Nr.ex 840979
Eex Ia Iic T6 Ptb Nr.ex 90.c2161x
Eex Ia Iic T4
Li=0 Ci=19nf
Max Values:
T6 30v, 100ma, 1.2w
T4 22v, 150ma, 1.2w
Eexd Iib T6
Cesi Gp-88.b .048
Replacement Body Model: Stg644j-a10-503c
Prom.: 1390403812
Press.rating: 750 Psi
Range Limits: -14.2 To 500 Psi
Span Limits: 15 To 500 Psia
Fill: Sil
Head: Ss
Diaph.: Ss
53011336
Range: 0-2.5 Bar
Output: 4-20 Ma
Pt503
752752
U.s.a.
Weight : 4.320 Kg
Ref No : 153964
