Gic Mg53bh Voltage Monitoring Relay

Gic Mg53bh Voltage Monitoring Relay
Gic
Manufactured By: General Industrial Controls Private Limited.
Larsen & Toubro Limited
Supply Monitoring: Series –sm501
Uv: 55-95 %
Ov: 105-125%
On Delay: 0-15 Sec.
Blink: Asy
On: Rev
415 Un
Cat.id.: Mg53bh
Type: Phase And Voltage Control
Supply: 3ph-3w, 415vac, 47-63 Hz
Rev: R021|v047|d019
O/p: 5a (Res.) @ 240 Vac/ 28vdc
Ac-15: 3/1.5 A @ 120/240vac
Dc-13: 2/0.22/0.1 A @ 24/125/250vdc
Iec 60947
Wiring: Awg 24 To 12, Cu 60/75°c
Drive: Ph1/ø 3.5mm, Torque: 0.54 Nm (5 Lb.in)
For Terminal Connection Use Wires With 1.5 To 2.0 Mm2 Flat Lugs With Sleeve Only.
Made In India
Weight : 110 Gm
Ref No : 140165
