Gic Md21df Voltage Monitoring Relay 250v

Gic Md21df Voltage Monitoring Relay 250v
Manufactured By: Gic-General Industrial Controls Private Limited
Larsen & Toubro Limited
Supply Monitoring: Series-Sm175
Cat Id: Md21df
Type: Phase & Voltage Control
Supply: 3ph-3w, 208-480vac, 47-63hz
Rev: R022|V030|D19
Relay O/P: 5a (Res.) @ 250 Vac/30vdc, 1c/O
Iec 60947
Ac-15: 3.0/1.5a @120/240 Vac
Dc-12: 2.0/0.22/0.1a @24/125/250 Vac
Wiring: Awg 20 To 12, Cu 60/75°C
Drive: Combi Head Bit / ø4.5
Min Torque- 0.5nm, (4.4 Lb.In.)
Max Torque- 0.7nm, (6.2 Lb.In.)
Sm 175
Un: 208 To 480
Uv%: -2 To -20
Ov% 2 To 20
Rt: 0 To 15 Sec
Made In India
Weight : 60 Gm
Ref No : 179695
